919 Dumping Coolant - Wrist Twisters

Thread Tools Display Modes
post #1 of 21 Old 06-20-2014, 09:13 AM Thread Starter
Road Pilot

Wolf's Avatar

Join Date: Mar 2013
Location: Dallas
Posts: 1,366
Rep Power: 1

Garage
919 Dumping Coolant

Recently went on a charity ride which was very slow and my motorcycle became very hot. The fan never turned on and it was pouring coolant out of the overflow hose underneath like a faucet. When it ran out of coolant it started steaming out of the hose like a teapot. It drained all the way to empty.

I refilled it but my bike is still draining coolant and the fan still will not turn on. Thanks WT in advance for any and all advice.
Wolf is offline
Sponsored Links
Advertisement

post #2 of 21 Old 06-20-2014, 09:25 AM
LDH
Test Rider

LDH's Avatar

Join Date: Feb 2006
Location: by the ocean
Posts: 4,417
Rep Power: 1


Awards Showcase
Trackday Recognition Referral Award
Total Awards: 2

Sounds like you overheated it and blew a headgasket. Probably got some head warpage too.

LDH is offline
post #3 of 21 Old 06-20-2014, 11:24 AM
Burn-em Upus Asphaltus

rickard919's Avatar

Join Date: Apr 2008
Location: Calgary, Canada
Posts: 3,802
Rep Power: 1


Awards Showcase
Donation
Total Awards: 1

A friend recently had a similar problem with a different bike. Turned out to be his thermostat. You could test yours in a lot of water on the stove to see if it opens. I hope you didn't damage your engine.

Spoiler:

rickard919 is offline

post #4 of 21 Old 06-20-2014, 11:57 AM
Tesserarius

CKutz_GO's Avatar

Join Date: Feb 2014
Location: Frederick
Posts: 607
Rep Power: 1

Quote:
Originally Posted by Wolf View Post
Recently went on a charity ride which was very slow and my motorcycle became very hot. The fan never turned on and it was pouring coolant out of the overflow hose underneath like a faucet. When it ran out of coolant it started steaming out of the hose like a teapot. It drained all the way to empty.

I refilled it but my bike is still draining coolant and the fan still will not turn on. Thanks WT in advance for any and all advice.
And ya never thought to turn it off?

really hope it's not wrecked man

try jumping the fan to see if it works, if so must be thermostat is toast. ...no pun intended

CKutz_GO is offline
post #5 of 21 Old 06-20-2014, 12:09 PM
Dewbie

bacis's Avatar

Join Date: May 2012
Location: Los Angeles
Posts: 237
Rep Power: 1

Mine did that once and it turned out I hadn't plugged the fan back in after checking valve clearances. Hope it's something simple like that.

bacis is offline
post #6 of 21 Old 06-20-2014, 02:16 PM Thread Starter
Road Pilot

Wolf's Avatar

Join Date: Mar 2013
Location: Dallas
Posts: 1,366
Rep Power: 1

Garage
Quote:
Originally Posted by CKutz_GO View Post
And ya never thought to turn it off?

really hope it's not wrecked man

try jumping the fan to see if it works, if so must be thermostat is toast. ...no pun intended
Didn't have the gauges connected to know how hot it was .
Wolf is offline
post #7 of 21 Old 06-20-2014, 02:18 PM Thread Starter
Road Pilot

Wolf's Avatar

Join Date: Mar 2013
Location: Dallas
Posts: 1,366
Rep Power: 1

Garage
Quote:
Originally Posted by LDH View Post
Sounds like you overheated it and blew a headgasket. Probably got some head warpage too.
I really hope that isn't the case. How will I know? It rides fine till it gets warm, then the gears become increasingly difficult.
Wolf is offline
post #8 of 21 Old 06-20-2014, 02:34 PM
Community Moderator

g00gl3it's Avatar

Join Date: Jun 2009
Location: Idaho
Posts: 11,616
Rep Power: 1


Awards Showcase
Wrist Twisters Event Attendance Wrist Twisters Event Attendance Wrist Twisters Event Attendance
Total Awards: 3

Quote:
Originally Posted by Wolf View Post
I really hope that isn't the case. How will I know? It rides fine till it gets warm, then the gears become increasingly difficult.
What do you mean the gears get more difficult? Like harder to shift?

Or it seems like the engine is struggling more as it gets hotter?

If the latter is true, you've more than likely hosed your engine and your rings are starting to bind in the bore, I'd guess. My old dirt bike did that and I still remember what it felt like right before it seized.

The 919 engine is pretty tough, though. Change your oil asap, and get a new thermostat. Get your gauges on before doing too much more so you know how hot it's getting, then test again.

2009 Aprilia Tuono - Ginger
2001 XR650R BRP (Big Red Pig)
2006 Honda 599 - Ex wrecked it :-D
2007 Honda CB900F (sold)
2006 Honda VTX 1300C (sold)
YouTube Channel
g00gl3it is offline
post #9 of 21 Old 06-20-2014, 03:10 PM
Tirone Choolaces

marylandmike's Avatar

Join Date: Aug 2007
Location: USA
Posts: 11,147
Rep Power: 1

Garage

Awards Showcase
Wrist Twisters Event Attendance Donation Donation
Total Awards: 3

The fan control relay gets the signal to activate from the ECU. The ECU, I am guessing gets the temperature from the Engine Coolant Temperature (ECT) Sensor circuit. Just wondering if not having the gages installed makes that ECT sensor circuit not give the proper signal to the ECU, and in turn the ECU not activating the the fan control relay?

marylandmike is online now
post #10 of 21 Old 06-20-2014, 03:56 PM
Tesserarius

Nickr919's Avatar

Join Date: Oct 2013
Location: Corona
Posts: 734
Rep Power: 1

Quote:
Originally Posted by Wolf View Post

I really hope that isn't the case. How will I know? It rides fine till it gets warm, then the gears become increasingly difficult.
Simple enough, your oil will be milky brown.

Nickr919 is offline
post #11 of 21 Old 06-20-2014, 04:38 PM
`

zaq123's Avatar

Join Date: Apr 2009
Location: here n' there
Posts: 3,842
Rep Power: 1


Awards Showcase
Wrist Twisters Event Attendance Wrist Twisters Event Attendance Wrist Twisters Event Attendance Wrist Twisters Event Attendance
Total Awards: 17

Quote:
Originally Posted by Nickr919 View Post
Simple enough, your oil will be milky brown.
not always the case. The best way to check for any heat related issues (head, gaskets, valves et) is to perform leak down test. Google it.

zaq123 is offline
post #12 of 21 Old 06-21-2014, 05:25 AM Thread Starter
Road Pilot

Wolf's Avatar

Join Date: Mar 2013
Location: Dallas
Posts: 1,366
Rep Power: 1

Garage
Quote:
Originally Posted by g00gl3it View Post
What do you mean the gears get more difficult? Like harder to shift?

If the latter is true, you've more than likely hosed your engine and your rings are starting to bind in the bore, I'd guess. My old dirt bike did that and I still remember what it felt like right before it seized.
Damnit! It's the first. I have been keeping this bike because it saved my life and I love the memories with it... But if I have to replace the engine so much of it will be changed that it won't be the same bike.

I'm going to take it to a friend (best in Tulsa for engines) and see if it can be saved. If I do an engine swap I will part out the goodies and sell the 919. Before the vultures start circling my brother gets first dibs.


Wolf is offline
post #13 of 21 Old 06-21-2014, 09:10 AM
Robert

HRC27's Avatar

Join Date: Aug 2013
Location: NE Florida
Posts: 1,126
Rep Power: 1

Garage
I wish you the best of luck brother.

Robert

2002 Honda 919
2003 Honda CRF450R
HRC27 is offline
post #14 of 21 Old 06-22-2014, 09:10 AM
Tesserarius

Nickr919's Avatar

Join Date: Oct 2013
Location: Corona
Posts: 734
Rep Power: 1

Quote:
Originally Posted by zaq123 View Post
not always the case. The best way to check for any heat related issues (head, gaskets, valves et) is to perform leak down test. Google it.
Consider it googled, I just though since he was losing so much coolant, the odds of it ending up in the engine were decent.

Ive never blown a head gasket but have replaced one on my fathers boat, not the worse job ever I just hope the issue could be solved that easily.

Keep us updated wolf! The vultures aren't buzzing yet

Nickr919 is offline
post #15 of 21 Old 06-22-2014, 01:26 PM
`

zaq123's Avatar

Join Date: Apr 2009
Location: here n' there
Posts: 3,842
Rep Power: 1


Awards Showcase
Wrist Twisters Event Attendance Wrist Twisters Event Attendance Wrist Twisters Event Attendance Wrist Twisters Event Attendance
Total Awards: 17

Quote:
Originally Posted by Nickr919 View Post
Consider it googled, I just though since he was losing so much coolant, the odds of it ending up in the engine were decent. Ive never blown a head gasket but have replaced one on my fathers boat, not the worse job ever I just hope the issue could be solved that easily. Keep us updated wolf! The vultures aren't buzzing yet
sometime head gasket let the coolant out into combustion chamber. No sights of it in the oil but engine will blow white steam out of the exhaust. Leak down is very easy and basically ultimate engine test. Valves, pistons, rings, head/head gasket etc can be checked with the leak down test. No need to buy any expensive tools. One can build the tester for under $40-50.

zaq123 is offline
post #16 of 21 Old 06-22-2014, 01:35 PM
LDH
Test Rider

LDH's Avatar

Join Date: Feb 2006
Location: by the ocean
Posts: 4,417
Rep Power: 1


Awards Showcase
Trackday Recognition Referral Award
Total Awards: 2

My last blown head gasket forged combustion gases into the cooling system. Would spew out the overflow, but never steamed from the exhaust or entered the oil system.

LDH is offline
post #17 of 21 Old 06-22-2014, 04:00 PM
`

zaq123's Avatar

Join Date: Apr 2009
Location: here n' there
Posts: 3,842
Rep Power: 1


Awards Showcase
Wrist Twisters Event Attendance Wrist Twisters Event Attendance Wrist Twisters Event Attendance Wrist Twisters Event Attendance
Total Awards: 17

Quote:
Originally Posted by LDH View Post
My last blown head gasket forged combustion gases into the cooling system. Would spew out the overflow, but never steamed from the exhaust or entered the oil system.
hopefully it's not the case in wolfs situation but very possible if he overheated the bike. Wolf, you can always to do a pressure test of your engine before you get the leak down tester. Get a hose end from the compression tester, screw it into the spurk plug, put the engine into TDC and keep it there with a breaker bar. Make sure to have someone hold the breaker bar or tie it securely so it won't move once you apply the air pressure. Again, secure the bar so it doesn't hit you in your nuts/head etc, very important. Connect the hose to your compressor with about 100 psi. Again, make sure that your bar is not about to whack you. Once pressure applied, look for signs of escaping air. Coolant bubbling in your radiator, air coming out of the oil fill hole - warped head/blown head gasket. Tailpipe - exhaust valve/seat, cylinder head gasket, cylinder head. Throttle body, intake, or air filter - intake valve/seat, cylinder head gasket, cylinder head. Radiator - cylinder head gasket, cylinder head PCV, Breather, or other crankcase opening - piston rings, cylinder wall, piston, cylinder head gasket, cylinder head. Outside - spark plug, cylinder head gasket, cylinder head, DI fuel injector

zaq123 is offline
post #18 of 21 Old 06-23-2014, 01:43 PM
Princeps Prior

redline919's Avatar

Join Date: May 2012
Location: Cincinnati
Posts: 1,894
Rep Power: 1

I had something similar happen on a Gsxr I had. Turns out the radiator cap wasn't sealing, and when the coolant got hot it would just come out of the overflow. Bypassing the seal in the cap. Good luck brother! It's usually the simple things. Check fuses and relays. Put power to the fan. Check thermostat. Hope for the best

redline919 is offline
post #19 of 21 Old 06-24-2014, 02:52 PM
Tesserarius

CKutz_GO's Avatar

Join Date: Feb 2014
Location: Frederick
Posts: 607
Rep Power: 1

Quote:
Originally Posted by Wolf View Post

Damnit! It's the first. I have been keeping this bike because it saved my life and I love the memories with it... But if I have to replace the engine so much of it will be changed that it won't be the same bike.

I'm going to take it to a friend (best in Tulsa for engines) and see if it can be saved. If I do an engine swap I will part out the goodies and sell the 919. Before the vultures start circling my brother gets first dibs.
Hey man even people get heart transplants. Don't give up too easily! Good luck!

CKutz_GO is offline
post #20 of 21 Old 07-07-2014, 01:59 PM Thread Starter
Road Pilot

Wolf's Avatar

Join Date: Mar 2013
Location: Dallas
Posts: 1,366
Rep Power: 1

Garage
Update!

Thanks everyone for the great troubleshooting info and advice!

Trying all the cheap easy fixes first. Fan fuse blew and I replaced it. Checked the thermostat, thermostat checked out. Like redline, my friend also suggested to replace the radiator cap. He said "There is a spring that pushes that rubber seal down onto the radiator and if the spring gets weak or the seal isn't sealing it will cause it to leak out of the overflow hose". It's worth a $10 try. If that doesn't stop the leak, it's most likely the head gasket.

She's running great too btw. I ran it at the track and pulled off advanced class times at the local track . She still keeps up with the R1s, I am just frequently checking my coolant levels.
Wolf is offline
post #21 of 21 Old 07-07-2014, 02:43 PM
Princeps Prior

redline919's Avatar

Join Date: May 2012
Location: Cincinnati
Posts: 1,894
Rep Power: 1

Quote:
Originally Posted by Wolf View Post
Thanks everyone for the great troubleshooting info and advice!

Trying all the cheap easy fixes first. Fan fuse blew and I replaced it. Checked the thermostat, thermostat checked out. Like redline, my friend also suggested to replace the radiator cap. He said "There is a spring that pushes that rubber seal down onto the radiator and if the spring gets weak or the seal isn't sealing it will cause it to leak out of the overflow hose". It's worth a $10 try. If that doesn't stop the leak, it's most likely the head gasket.

She's running great too btw. I ran it at the track and pulled off advanced class times at the local track . She still keeps up with the R1s, I am just frequently checking my coolant levels.
Is it still overheating/losing coolant since replacing the fan fuse? Just curious.

redline919 is offline
